MON HP 27" EliteDisplay E27D G4 (6PA56A4)

Display specifications

Display size (diagonal)

60.96 cm (24”)

Panel active area

51.84 x 32.4 cm

Aspect ratio

16:10

Native resolution

WUXGA (1920 x 1200 @ 60 Hz)

(The Display can support up to 75Hz refresh for some video modes. The video card of the connected PC must be capable of supporting 75Hz. The preferred Mode is 1920 x 1080 @ 60 Hz.)

Resolutions supported

•

• 1920 x 1200

• 1920 x 1080

• 1680 x 1050

• 1600 x 900

• 1440 x 900

• 1280 x 1024

• 1280 x 800

• 1280 x 720

• 1024 x 768

• 800 x 600

• 720 x 480

• 640 x 480


Pixel pitch

0.27 mm

Brightness

300 cd/m² ¹

Contrast ratio

1000:1 static

10000000:1 dynamic ¹

View angle

178° horizontal

178° vertical

Response time

5 ms gray to gray ^1,3

Tilt and swivel angle

Tilt: -5 to +22°

Swivel: ±45°

Pivot rotation: 90°

Height: 150 mm

Display features

Anti-glare

In plane switching

Language selection

LED Backlights

On-screen controls

Pivot rotation

Plug and Play

User programmable

Low Haze

Physical security

Security lock-ready (lock is sold separately)

VESA mount

•

• 100 mm


Connectivity

Input connector

1 DVI-D

1 HDMI 1.4

1 DisplayPort™ 1.2

(with HDCP support on DisplayPort™ and HDMI )

Ports

1 analog audio output

3 USB 3.0 (downstream)

1 USB 3.1 Type-C™ (side, downstream, power delivery up to 10 W)

1 USB 3.1 Type-C™ (rear, downstream and upstream, power delivery up to 15 W) ¹

Dimensions and weight

Weight

7.2 kg

(With stand)

Product dimensions without stand (W x D x H)

53.2 x 4.68 x 35.1 cm

(Without stand)

Dimensions With Stand (W x D x H)

53.2 x 21.4 x 50.3 cm

Power and operating requirements

Power supply

•

• Input voltage: 100 to 240 VAC


Power consumption

•

• 92 W (maximum)

• 40 W (typical)

• 0.5 W (standby)


Power consumption (on-mode)

36 W

Power consumption

53 kWh

Power consumption (standby)

0.5 W

Power consumption (off-mode)

0.3 W

Operating temperature range

5 to 35°C

Operating humidity range

20 to 80% RH

Energy efficiency class

•

• B


Environmental

•

• Arsenic-free display glass

• Mercury-free display backlights

• Low halogen


Energy Efficiency

Energy efficiency class

•

• B


Display size (diagonal)

60.96 cm (24”)

Power consumption (on-mode)

36 W

Power consumption

53 kWh

Power consumption (standby)

0.5 W

Power consumption (off-mode)

0.3 W

Resolution (native)

WUXGA (1920 x 1200 @ 60 Hz)

Certification and compliance

Certifications and compliances

•

• BSMI

• CB

• CCC

• CE

• CEL

• cTUVus

• CU

• ErP

• FCC

• ICES

• ISC

• ISO 9241-307

• Mexico CoC

• Microsoft WHQL Certification (Windows 10 and Windows 7)

• MSIP

• RCM

• SmartWay Transport Partnership - NA only

• VCCI

• WEEE
